What is the VIZDesign Standard?
Select paid version price period
1 year
xxxxxx KRW
3 year10% Discount
xxxxxx KRW
- To use the official version, you need to purchase a license code.
- A network license is available to multiple users with one license (limited number of concurrent connections).
- Each license code allows you to select its expiration date.
- Payment can be made by credit card, account transfer, or deposit without a bankbook.
Function
Features
01
CAD import
- STRANDARS
- SIEMENS
- DASSAULT SYSTEMS
- AUTODESK
- PTC
- Other
02
ISO/MOUSE KEY
- CATIA V5
- UGNX
- Solidworks version support
03
Area capture
- Quickly create images
- Shading/hidden line processing
- Selectable background color: primary color or white
- After selecting an area
- Paste directly into a document
04
File compression
- CATIA file with 660 parts and 512MB takes 25 seconds to open
- When saved in .viz format, it is saved as a single file and compressed to 7MB
- Opening speed reduced from 25 seconds to 5 seconds
05
Single measurement
- Hole coordinates, length (arc), normal angle
- Measurement of hole depth, diameter, and radius
06
Attribute measurement
- Bounding box, weight, volume, surface area (surface), volume, center of gravity, linear distance, thickness measurement
- Angle (BC angle), slope angle measurement
07
Section work
- Basic section, section box, inbox section, selected section, continuous section, section color change
- 2D projection of section and saving as DWG, PDF, or HPGL
08
Change reference axis (setup)
- Change the reference axis after creating the normal axis
- Slanted product setup possible
09
3D file conversion
- VIZDesign: VIZ (lightweight), VIZM (mobile)
- STANDARDS: STP, IGS, PRC, STL, U3D, OBJ, glTF
- SIEMENS: Parasolid, JT
- DASSAULT SYSTEMES: ACIS
- AUTODESK: FBX
- OTHER: VRML, 3MF
10
2D drawing comparison
- Compare drawings before and after design changes
- Colorize different areas to instantly identify modified areas
11
Reading 2D drawings
- Open DWG/HPGL
- Added 2D review information management
- 2D dimension measurement
- 2D parts list creation
- 2D area capture/printing
12
2D view projection
- Project 2D views using the first-angle/third-angle method and save as DWG/DXF
- Create car lines, apply face colors, remove hidden lines, and create an origin
- Relative axis projection (origin-shift projection)
13
Save notes (markups)
- Symbol Addition Feature
- Automatic part name generation when manually entering or selecting a model
14
Part Search
- Enter search term and search
- Search by assembly/body unit
- Export model tree and save to Excel
15
Snapshot (scene save)
- Save your work in progress
- Create a video file of the saved scene
License structure
Nodelock (fixed)
It can only be used on a single device and cannot be used over a network.
Floating (simultaneous connection)
It can be used on all devices on the network, and the number of users equal to the number of purchased licenses can connect and use it simultaneously.
Comparison
| Features and License Types | Standard | Pro |
|---|---|---|
ISO Display / Mouse Control (CATIA, NX, Solidworks, Default) / PMI | ||
Dimension Measurement (Bounding Box, Weight, Volume, Surface Area, Hole, Angle) | ||
Crosssection Operation (In-Box, Box, Plan) | ||
2D Projection and Saving as DWG / Cross-Section 2D Projection | ||
Reference Axis Change (Base Axis), Setup Functions, Translation, Rotation, Mirroring, Exploding | ||
3D File Conversion (ACIS, STEP, IGES, JT, Parasolid, STL, U3D, VTML) | ||
2D PRT / CATDrawing Reading | ||
Mold Factor Calculation / BOM Parts List / Projected Area Calculation | ||
Interference Check / Draft Analysis / Undercut Analysis | ||
3D Model Comparison / Automatic Exploding / 3D Animation |
Supported formats
Supported
Partial or variable support
Unsupported
This concept is not supported by this format
This file format provides tessellation data
| Format | Version | TESS. | BREP | PMI |
|---|---|---|---|---|
ACIS SAT, SAB | Up to 2023 | |||
CATIA V4 MODEL, SESSION, DLV, EXP | Up to 4.2.5 | |||
CATIA V5 CATPRODUCT, CATPART, catshape, CGR | Up to V5_6R2024 | |||
CATIA V6 / 3D Experience 3DXML | Up to V5_6R2024 | |||
Creo - Pro/E ASM, NEU, PRT, XAS, XPR | Pro/E 19.0 to Creo 10.0 | |||
I-deas MF1, ARC, UNV, PKG | Up to 13.x (NX5) / NX I-deas 6 | |||
IGES IGS, IGES | 5.1, 5.2, 5.3 | |||
Autodesk Inventor IPT, IAM | Up to 2025 | |||
GL Transmission Format .gltf, .glb | Version 2.0 only | |||
JT JT | Up to V10.9 | |||
NX - Unigraphics PRT | UG11 to UG18, UG NX, NX5 to NX12, NX1847 to NX2312 | |||
PRC PRC | All Version | |||
Parasolid X_T, X_B, XMT, XMT_TXT | Up to V36.1 | |||
Rhino 3DM | From 4 to 8 | |||
STEP Stp, step, stpz | AP 203 E1/E2, AP 214, AP 242 | |||
STEP XML Stpx, stpxz | Any | |||
Stereo Lithography .stl | All versions | |||
Solid Edge .par, .asm, .pwd, .psm | 1 to 20, ST1 to ST10, 2019 to 2024 | |||
Solidworks .sldprt, .sldasm | From 97 up to 2024 | |||
Universal 3D .u3d | ECMA-363 | |||
VDA-FS .vda | Version 1.0 and 2.0 | |||
VRML .wrl, .vrml | Version 1.0 and 2.0 | |||
Wavefront OBJ .obj | Any | |||
Autodesk Revit .rvt, .rfa | 2015 to 2024 | |||
Autodesk 3DS 3DS | Any | |||
COLLADA DAE | Any | |||
Autodesk DWF .dwf, .dwfx | Any | |||
FBX FBX | Ascii from 7100 to 7400 Bi. All |
Product support
VIZDesign Standard VIZDesign V9 Compatible Format
2025.08.18
VIZDesign Standard Technical Document
Product Name: VIZDesign Standard Version: 9.0 Overview: VIZDesign Standard is a lightweight 3D viewer designed for
2025.08.18
VIZDesign Standard Product
Overview: VIZDesign Standard is a lightweight 3D viewer developed using 100% proprietary Korean technology. It
2025.08.18
System Requirements
Software
OS
Windows 10 or higher (64-bit)
Hardware
CPU
Intel i7 or higher recommended
RAM
16GB or more
GPU
OpenGL 4.5+, NVIDIA GTX1060 or better
